Panel-Ready 24” Double-Refrigerator Drawers

Panel-Ready 24” Double-Refrigerator Drawers

Signature Features

Fully Flush, Built-In Design

Allows the under counter double drawers to disappear into existing cabinets and integrate with other appliances.

Custom Overlay Design

Custom Overlay Design perfectly blends the Double Drawers with surrounding cabinetry. Requires custom handle(s) and panel(s) (not included).

Temperature Presets

Allows you to optimize the temperature inside each drawer based on storage needs, with pre-programmed selections.

Dual Zone Temperature System

Allows drawers to be kept at two separate temperatures to create optimum storage conditions for different foods.

Automatic Interior LED Lighting

Bright, long-lasting Automatic Interior LED Lighting illuminates when a drawer is opened.

Max Cool Option

The Max Cool option keeps internal temperatures extra cold for 24 hours to protect ingredients while loading groceries, during heavy usage or with temporarily warm room temperatures.

Light-Guided Electronic Controls

Combine a sleek, concealed design with intuitive response that makes it easy to set the temperature inside each drawer.

Fully Extendable Soft-Close Drawers

Provide easy access to all items, even those that are stored in the back, and feature a soft-close system to ensure the drawers close completely.

Sabbath Mode

Allows the Double Drawers to comply with requirements for the Sabbath or other religious holidays without turning on any lights when a drawer is opened.

Technical Specifications

Exterior Details


Door Color: Panel Ready
Door Opening Direction: N/A
Door Style: Flat
Handle Material: Metal
Reversible Door: No
Window: No

Certifications


ADA Compliant: No
ENERGY STAR Qualified: No
Prop 65: Standard
Energy Star® Qualified: No

Details


Refrigerator Type: Refrigerator - Freezer Drawers
Zone 1 Temperature Range: 32F to 42F
Zone 2 Temperature Range: 32F to 42F
Installation Option: Undercounter

Filter Details


Water Filter Indicator/Reset: No

Refrigerator Details


Number of Temperature Controlled Zones: 2

Interior Details


Interior Light: LED
JUD24FRECX
Panel-Ready 24” Double-Refrigerator Drawers

Dimensions


Depth Closed Excluding Handles: 23-7/8 in
Depth Closed Including Handles: 26 in
Gross Weight: 153 lbs
Height: 34-3/4 in
Height To Top Of Cabinet: 34-1/8 in
Height To Top Of Door Hinge: 34-3/4 in
Net Weight: 0 lbs
Width: 23-7/8 in
Depth: 26 in
Maximum Height: 34-3/4 in
Minimum Height: 34-1/8 in
Capacity: 4.7 cu. ft.

Controls


Automatic Defrost: Yes
Control Lockout: No
Cooling On/Off: Yes
Door Ajar/Open Alarm: Yes
Max Cool/Fast Cool: Yes
Sabbath Mode: Yes

Electrical


Amps: 15
Volts: 115
